Ansible is a powerful automation tool that simplifies the management and configuration of network devices. Automating Cisco switch configurations with Ansible not only saves time but also ensures consistency and reduces human errors, making it an indispensable skill for network professionals.
If you’re new to Ansible, I recommend reviewing these foundational articles:
- Ansible: The Magic of Automation — Introduction & Installation
- Ansible: Mastering Its Structure for Effective Automation
Initial Setup
Before diving into automation, ensure the following prerequisites are met:
- SSH Access: Ensure SSH access is enabled on your Cisco switches.
- User Privileges: Create users with the appropriate privileges for configuration tasks.
- SSH Key Setup: Generate and deploy SSH keys for secure, password-less access:
$ ssh-keygen -t rsa -b 2048
$ ssh-copy-id user@switch_ip
Core Ansible Modules for Cisco Switches
Ansible provides specialized modules for managing Cisco devices. The two most commonly used modules are:
- ios_config : Pushes configuration changes to Cisco switches.
- ios_command : Executes commands on Cisco devices and retrieves their output.
Disabling Unnecessary Service
-name: Disable Unnecessary Services
ios_config:
lines:
-no lldp run
-no ip finger
-no ip http server
-no ip http secure-server
Gathering Running Configuration
-name: Gather Running Configuration
ios_command:
commands:
-show running-config
Creating and Executing Playbooks
Basic Playbook: Configuring VLANs on a Cisco Switch
In basic example, we configure VLAN 10 on a Cisco switch. Note that the host, username, and password are specified within the playbook itself.
name: Basic VLAN Configuration on Cisco Switch
hosts: switches
tasks:
name: Create VLAN 10
ios_config:
lines:
vlan 10
name Sales
provider:
host: “{{ inventory_hostname }}”
username: “{{ ansible_user }}”
password: “{{ ansible_ssh_pass }}”
authorize: yes
auth_pass: “{{ ansible_become_password }}
Advanced Playbook: Configuring VLANs with Inventory Management
In advanced example, we centralize the management of connection details in the inventory file ( inventory/host.yaml ). This approach eliminates redundancy and simplifies playbookmaintenance.
Inventory File ( inventory/host.yaml ):
[switches]
192.168.1.111
192.168.1.112
[switches:vars]
ansible_connection=ansible.netcommon.network_cli
ansible_user=[USERNAME]
ansible_password=[PASSWORD]
ansible_become=yes
ansible_become_method=enable
ansible_become_pass=[ENABLE_PASS]
ansible_network_os=cisco.ios.ios
ansible_ssh_common_args=’-o ConnectTimeout=240
- 192.168.1.111 : The IP address of the Cisco switch.
- ansible_connection=ansible.netcommon.network_cli : Specifies the connection method as network CLI.
- ansible_user : SSH username.
- ansible_password : SSH password.
- ansible_become=yes : Enables privilege escalation.
- ansible_become_method=enable : Uses the enable method for privilege escalation.
- ansible_become_pass : Password for privilege escalation.
- ansible_network_os=cisco.ios.ios : Specifies the network OS as Cisco IOS.
- ansible_ssh_common_args=’-o ConnectTimeout=240′ : Sets the SSH connection timeout to 240 seconds.
Playbook Content:
name: Advanced VLAN Configuration on Cisco Switch
hosts: switches
tasks:
-name: Advanced VLAN Configuration on Cisco Switch
hosts: switches
tasks:
-name: Configure VLAN 10
ios_config:
parents: “vlan 10”
lines:
-name Sales
- parents use for Interfaces too!
Advanced Configuration Topics
Backup and Recovery
Regular backups of switch configurations are critical for disaster recovery. Use the following playbook to automate backups:
-name: Backup Switch Configuration
hosts: switches
tasks:
-name: Capture running configuration
ios_command:
commands: show running-config
register: backup
-name: Save backup to file
copy:
content: “{{ backup.stdout }}”
dest: “/backup/switch_{{ inventory_hostname }}.cfg”
- Store backups in a structured directory and schedule periodic backups using cron or Ansible Tower .
Configuring DHCP and DNS on Cisco Switches
Automate the configuration of DHCP and DNS services on your switches:
-name: Configure DHCP Server on Cisco Switch
hosts: switches
tasks:
Configure DHCP pool for VLAN 10
ios_config:
lines:
ip dhcp pool VLAN10
network 192.168.10.0 255.255.255.0
default-router 192.168.10.1
dns-server 192.168.10.1
Other Configs has same structure!
Using Tags in Playbooks
Tags allow you to selectively run specific tasks within a playbook. You can apply tags at the task or play level.
Example Playbook with Tags
name: Example Configure
-name: Example Configure
-hosts: switches
gather_facts: false
tasks:
-name: Configure EIGRP
ios_config:
src: “eigrp_template.j2”
match: none
tags:
-eigrp
-template
-tag1
-name: Configure Hostname
ios_config:
lines: hostname {{ inventory_hostname }}
tags:
-hostname
-tag1
Running Playbooks with Tags
- List all tasks:
- ansible-playbook tags.yaml –list-tasks
- List all tags:
- ansible-playbook tags.yaml –list-tags
- Run specific tasks by tag:
- ansible-playbook tags.yaml –tags hostname
- ansible-playbook tags.yaml –tags eigrp
- ansible-playbook tags.yaml –tags “eigrp,hostname”
- Skip specific tasks by tag:
- ansible-playbook tags.yaml –skip-tags eigrp
- ansible-playbook tags.yaml –skip-tags “eigrp,hostname”
Conditional Tasks
Use conditional logic to execute tasks based on specific conditions:
File group_vars/all.yml:
ntp_enabled: true
Playbook:
-name: Conditional NTP Configuration
hosts: switches
vars_files:
-group_vars/all.yml
tasks:
-name: Check if NTP should be configured
ios_config:
lines:
-ntp server 10.180.25.36
when: ntp_enabled | default(false)
In this example if ntp_enabled is empty or any things instead of true , It is not possible
and will be rejected(skip)!
Attention to Errors
Paying attention to errors is critical. Carefully reading and understanding them helps you quickly resolve issues.
Here’s an example of an SSH connection error:
fatal: [192.168.1.102]: FAILED! => {“changed”: false, “msg”: “ssh connection failed: ssh connect
failed: No route to host”}
- Analyze and address such errors swiftly to maintain smooth network operations.
- The solution to this problem is to enable SSH, create a user with high privilege, and finally check the ACCESS-List related to the SSH device.
Mastering Ansible is a game changer for achieving seamless, high quality network integration. With Ansible, you can swiftly and accurately deploy all network configurations, including security setups, using intelligent playbooks. This empowers you to streamline your processes, reduce errors, and enhance the efficiency of your network operations.
By embracing Ansible, you position yourself at the forefront of network automation, ensuring that your configurations are both robust and reliable.
Start automating today and unlock the full potential of your network! Itsg and Cisco Switch for every network.
